Product description
Design Wall-mounted EMC
Product description EMC fan-and-filter units offer a high shielding/attenuation effect and meet
requirement category 2 to EN 61587-3.
Benefits Easy filter changes, thanks to a new opening mechanism on the louvred grille
Faster installation on the enclosure with optimised detent hooksDiagonal fan
Technology achieves more even and constant ventilation of the enclosure,
Thanks to improved pressure stabilityTool-free assembly
Material Plastic
Colour RAL 7035
Supply includes Complete unit ready to install, including EMC filter mat
Fan Diagonal, EC motor
Air throughput,
unimpeded airflow (with chopped-fibre filter) At 50 Hz: 931 m³/h
Air throughput with matching outlet filter
including chopped-fibre filter At 50 Hz: 728 m³/h
Rated operating voltage 200 V - 240 V, 1~, 50 Hz/60 Hz
Power consumption Pel At 50 Hz: 173.5 W
Rated current max. At 50 Hz: 1.38 A
IP protection category to IEC 60 529 IP51 with chopped-fibre filterIP 56 with chopped-fibre filter and hose-proof hood
Protection category NEMAType 12 with chopped-fibre filterType 3, 3R with chopped-fibre filter and
hose-proof hood
Note To improve energy efficiency and extend the service life of the devices, we
recommend the use of thermostats or temperature displays
Operating temperature range -25 °C...55 °C
Storage temperature range -25 °C...70 °C
Noise level At 50 Hz: 72 dB(A)
Interfaces 0 - 10 V/PWM inputSpeed outputFloating fault signal contactRS485 (ModBus)
Net weight 4.01 kg
Gross weight 4.218 kg
ETIM 9 EC000320
ETIM 8 EC000320
ECLASS 8.0 27180716
