Version | ETIM-9 |
Class | EC001324 - CEE socket outlet, disconnectable, with fuse (IEC 60309) |
IEC-amperage | 16 |
Number of poles | 5 |
Voltage according to EN 60309-2 | 400 V (50+60 Hz) red |
Clock hour position | 6 |
Switch | Mechanical locking |
Type of switch | Special switch |
With earth leakage switch | FALSE |
Empty locations on mounting rail | FALSE |
Housing material | Plastic |
Model | Base unit and cover |
Protection | None |
Military model | FALSE |
Current | 16A |
Number of poles | 5p |
Arangement of phases | 3p+N+PE |
Position of earth contact | 6 h |
Voltage | 200/346 - 240/415V~ |
Frequency | 50/60Hz |
Protection degree | IP67 |
Colour code | red RAL 3000 |
Colour of appliance | Hinged lid red RAL 3000 Housing bottom grey RAL 7035 Housing screws grey RAL 7035 Bayonet ring grey RAL 7035 Housing top grey RAL 7035 Control knob grey RAL 7035 |
Connection design | screwless spring terminals with Kontex-Kontakt |
Maximum conductor size | 4,0 qmm |
Cable entry | top entry M25/M25 bottom entry M25 |
