Baying enclosure system VX25 Basic enclosure
Part No.:
8685000
Brand:
Availability:
Forward delivery 6-9 weeks
| Part No. | 8685000 |
|---|---|
| UOM | EA |
| Packaging Unit | EA |
| Material | Enclosure frame: Sheet steel, 1.5 mm Roof: Sheet steel, 1.5 mm Door: Sheet steel, 2.0 mm Rear panel: Sheet steel, 1.5 mm Gland plates: Sheet steel, 1.5 mm Mounting plate: Sheet steel, 3.0 mm |
| Protection category IP ACC IEC 60529 | IP 55 |
| Protection category NEMA | NEMA 12 |
| Scope of delivery | Enclosure frame Door(s) Door hinged on the right, may be swapped to the left Roof plate Rear panel Gland plates Mounting plate 2 punched rails 18 x 39 mm Lock: 3 mm double-bit |
| Weight (KG) | 90.00 |
|---|---|
| Dimension Width (mm) | 600.00 |
| Dimension Height (mm) | 1,800.00 |
| Dimension Depth (mm) | 500.00 |
Description
VX Baying enclosure system, WHD: 600x1800x500 mm, sheet steel, with mounting plate, single door at the front
